KTM Macina Alp LTD64
3.449,00 €
-18%
4.199,00 €
incl. VAT
free shipping*
The 2024 KTM Macina Alp LTD64 is an e-mountain bike with 29-inch wheels and an aluminium frame. Electric assistance is provided by the Bosch Performance CX Gen.4 Smart System motor, delivering 85 Nm of torque and assistance up to 25 km/h. It is paired with a Bosch PowerTube battery with a capacity of 750 Wh.
-
Bosch Kiox 300 display: Clearly displays navigation, ride data and fitness information on the 2.0-inch colour display.
-
Shimano Deore XT 11-speed drivetrain: Fitted with a Shimano LG400-11 cassette and 11–50 teeth.
-
RockShox Recon Silver RL suspension fork: Offers 120 mm of front suspension travel.
-
Shimano 4-piston brake system: Fitted with a combination of Shimano MT401 and MT420 calipers.
-
29-inch tyres: Schwalbe Nobby Nic Performance tyres at the front and rear complete the e-MTB setup.
Akku type
750 Wh - Bosch PowerTUBE 750Wh SMART SYSTEM hor.
Motor type
Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm
Display
Bosch LED remote SMART SYSTEM / Bosch KIOX 300 TFT Display SMART SYSTEM
E-Bike Components
| Motor manufacturer | Bosch |
| Motor type | Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm |
| Display | Bosch LED remote SMART SYSTEM / Bosch KIOX 300 TFT Display SMART SYSTEM |
| Akku | 750 Wh |
| Akku type | Bosch PowerTUBE 750Wh SMART SYSTEM hor. |
| Charger | Bosch STANDARD Charger 4A SMART SYSTEM |
Gears
| Rear derailleur | Shimano Deore XT M8130-11 LG shadow+ |
| Cassette | Shimano LG400-11 / 11-50T |
| Shifter | Shimano Deore XT M8130-11 LG |
Brakes
| Brake system | Shimano MT401 / MT420 4-Piston |
Cockpit & Seating
| Stem | KTM Team MTB 7° |
| Headset | Acros ICR 1.5" angle limit |
| Handlebar | KTM Comp II flat 2X 720mm |
| Handles | KTM Comp Lock |
| Seatpost | KTM Comp II 30.9/400 |
| Saddle clamp | KTM Line 34.9 |
| Saddle | KTM Line Sport |
Frame
| Frame | Macina MTB 29" Alloy6061; PT750Wh Bosch Gen.4 / M-2706 |
| Frame-Material | Aluminium |
| Wheel-Size | 29" |
| Fork | RockShox Recon Silver RL 29" 120mm 15x110 taper |
| Frametype | Diamant |
Suspension
| Front travel | 120mm |
Drive Unit
| Crank | KTM E-COMP ISIS 170mm Q16 |
| Chain | KMC e11 Sport EPT e-bike |
| Rims | F: KTM Line - Shimano MT410B CL 32H 110-15TA, Ambrosio E30 Trail 32H 622x30TC, DT ChampiR: KTM Line - Shimano MT400B CL 32H 148-12TA, Ambrosio E30 Trail 32H 622x30TC, DT Alpine II 2.34 black |
| Front tire | Schwalbe Nobby Nic Perf. Folding 62-622 |
| Rear tire | Schwalbe Nobby Nic Perf. Folding 62-622 |
Other
| Pedals | MTB-Pedal VP-195E alloy |
| Model year | 2024 |
| Color | Schwarz |
| Weight | 23,9 kg |
| Permissible total weight | 125 kg |
| EBikeKategorie | E-Mountainbikes |
| Gender | Unisex |
Compact display. Smart control.
The Bosch Kiox 300 is the compact smart display for sporty e-bike riding. Navigation, ride data and fitness information are clearly presented on the bright color screen, keeping everything important in view while you ride.
