KTM Macina Superbelt SX dark sea US 2026
3.329,10 €
-10%
3.699,00 €
incl. VAT
free shipping*
RIDE EASY. LIVE URBAN. While the Macina Urbanator SX embodies the sporty urban lifestyle, the new Macina Superbelt SX is aimed at all those who prefer to take it easy in the city. Comfort, lightness and a relaxed riding experience take centre stage here - ideal for daily commutes, relaxed after-work rides or weekend excursions. Thanks to the belt drive and hub gears, you can enjoy maintenance-free lightness that is insensitive to dirt, quiet and durable. The KTM innovation POWER TUBE TOP LOADER (PTTL) is also used throughout these models for user-friendly battery handling. The CompactTube 400WH battery can be removed from the top of the frame on all models. The simple process of removing and reinserting invites you to have a second battery with you for long tours. KTM provides clever solutions from the accessories range for precisely this purpose. Both the "Sport Trunk Bag" saddle bag and the "Battery Board" for the rucksack have been specially developed for stowing the second battery. The BOSCH PowerMore Range Extender with 250 WH offers another way to extend the range. This can be attached directly to the battery cover on the KTM SX models. The position of the charging socket has been specially adapted to this. E-biking has never been so "easy".
Akku type
400 Wh - Bosch CompactTUBE 400Wh - ABUS integrated btry lock IT2 (T82 key)
Motor type
Bosch PERFORMANCE SX BDU3144
Display
Bosch PURION 200 Display & Remote
Range Extender: PowerMore 250 (optional)
Tragbare Energiereserve: PowerMore 250 ist der trinkflaschengroße Zusatzakku für noch mehr Reichweite und länger anhaltenden Trail-Spaß. Kompakt und 1,5 Kilogramm leicht, lässt sich der Range Extender ganz einfach an der Trinkflaschenhalterung befestigen. Der Range Extender ist kompatibel mit diesem E-Bike.
E-Bike Components
| Motor manufacturer | Bosch |
| Motor type | Bosch PERFORMANCE SX BDU3144 |
| Display | Bosch PURION 200 Display & Remote |
| Akku | 400 Wh |
| Akku type | Bosch CompactTUBE 400Wh - ABUS integrated btry lock IT2 (T82 key) |
| Charger | Bosch COMPACT Charger 2A |
| Range Externder compatible | Ja |
| Range Extender | Bosch PowerMore 250 (optional erhältlich) |
Gears
| Cassette | Gates CDC CenterTrack Sprocket 22T |
| Shifter | Shimano Nexus 8 Revoshifter |
Brakes
| Brake system | Shimano MT402 (3-F) / MT410 2-Piston |
Cockpit & Seating
| Stem | KTM Line +20° ICR |
| Headset | Acros AICR intern 1.1/8"-1.5" angle lim |
| Handlebar | KTM TEAM II low rizer 640mm |
| Handles | Ergon GP1 short |
| Seatpost | KTM TEAM II 27.2/300 |
| Saddle clamp | KTM Line JD-SC99 - 31,8mm |
| Saddle | Selle Royal Vaia Gel |
Other Specs
| Luggage carrier | KTM Alumee snap-it 2.0/monkeyload|rack clip |
| Stand | KTM 28" adjustable MY2025 |
| Front light | Litemove RLX-100 100Lux down |
| Rear light | AXA Juno |
| Mudguards | SKS EVO AL 55mm 28" |
Frame
| Frame | Macina Trekking Onroad Alloy 6061|CPT400 Bosch BDU31/T6120 |
| Frame-Material | Aluminium |
| Wheel-Size | 28" |
| Fork | Suntour NCX-D Air LO 63mm 1 1/8 |
| Frametype | Tiefeinstieg |
Suspension
| Front travel | 63mm |
Drive Unit
| Crank | left: KTM E-TEAM2 ISIS 170mm Q8 - right: KTM E-TEAM2 ISIS 170mm Q8 |
| Chain | Gates CDC Drive-belt 118T |
| Front hub | Shimano Deore M5100 CL 32H 100-5QR |
| Rear hub | Shimano Alfine SG-S7001-8 CL 32H 135-10 |
| Front tire | Schwalbe Marathon Mondial Perf. RaceGuard 47-622 Reflex |
| Rear tire | Schwalbe Marathon Mondial Perf. RaceGuard 47-622 Reflex |
| Spokes | front: DT Champion 2.0 black - rear: DT Alpine II 2.34 black |
Other
| Pedals | Trekking-Pedal VP-616 anti-slip |
| Model year | 2026 |
| Color | Blau |
| Weight | 21,8 kg |
| Permissible total weight | 140 kg |
| EBikeKategorie | E-Trekking-Bikes |
| Gender | Unisex |
