UNNO MITH RS Race
9.995,00 € incl. VAT free shipping*
The same MITH.
- A completely different set-up. Raw forged carbon meets RockShox’s ‘Electric Red’ suspension.
- ZEB Ultimate at the front. Vivid Coil Ultimate at the rear.
Built to turn heads. Built to be fast.
Size chart:
- S1: 155 cm – 170 cm
- S2: 170 cm – 180 cm
- S3: 180 cm – 195 cm
Akku type
800 Wh - Avinox FS800 Wh
Motor type
AVINOX M2S (2,60kg Drive unit with 250W rated power)
Display
Avinox DP100 2" OLED smart multi-function touchscreen with 800 nits and 326 ppi
Maximum power in an ultra-compact package
The Avinox M2S combines enormous power with an exceptionally compact and lightweight design. With up to 150 Nm in Boost mode, intelligent power delivery and advanced thermal management, it is built for demanding climbs and aggressive e-MTB riding.
E-Bike Components
| Motor manufacturer | Avinox |
| Motor type | AVINOX M2S (2,60kg Drive unit with 250W rated power) |
| Display | Avinox DP100 2" OLED smart multi-function touchscreen with 800 nits and 326 ppi |
| Akku | 800 Wh |
| Akku type | Avinox FS800 Wh |
| Charger | Avinox 4A 4A Charger max. charging power 168 W |
| Steuergeraet | Avinox BC100 Wireless Controller with Bluetooth Connectivity |
Gears
| Rear derailleur | SRAM S1000 Eagle AXS Wireless - T-Type - 12 speed |
| Cassette | SRAM Eagle 70 XS 1270 T-Type, 10-52T V2 |
| Shifter | ONE UP / SRAM Right: SRAM AXS POD Control Left: ONE UP Mechanical Shifter |
Brakes
| Brake system | SRAM Maven Base / SRAM HS2 6-BOLT TYPE 200mm |
Cockpit & Seating
| Stem | ONE UP FORGED 42mm stem |
| Headset | CANE CREEK FORTY Series (IS41-42/28.6 - IS52/40) |
| Handlebar | ONE UP ALLOY Carbon handlebar, 35mm diameter, 800mm length, 35mm rise |
| Seatpost | ONE UP V3 Mechanical 31.6mm diameter with Travel of: 150 mm (S1), 175 mm (S2), 200 mm (S3) |
| Saddle | FIZIK Terra Aidon X5 145mm |
Frame
| Frame | T700/T1000 Carbon fiber monocoque with Forged Carbon finish and virtual pivot suspension. |
| Frame-Material | Carbon |
| Wheel-Size | Mullet |
| Fork | Rock Shox - ZEB ULTIMATE 29" BOOST ELECTRIC RED 170mm travel. 44mm offset. |
| Frametype | Diamant |
Suspension
| Front travel | 170mm |
| Rear shock absorber | Rock Shox - VIVID COIL ULTIMATE S1 - Coil 275lbs Vivid 230x65mm S2 - Coil 325lbs Vivid 230x65mm S3 - Coil 400lbs Vivid 230x65mm |
Drive Unit
| Crank | E13 Helix CORE E*SPEC |
| Chain | SRAM 70 T-TYPE 120 Link |
| Chainrings | E13 HELIX RACE E*SPEC 36T 8mm offset 55 mm CL |
| Front tire | SCHWALBE Magic Mary Ultra Soft Gravity Pro, TLR, 29” x 2.5” |
| Rear tire | SCHWALBE Magic Mary Soft Evo Gravity Pro, TLR, 27.5” x 2.5” |
| Wheelset | DT Swiss H1900 Mullet: 29" front and 27.5" rear with DT 370 hub |
Other
| Pedals | ohne |
| Model year | 2027 |
| Color | Schwarz |
| EBikeKategorie | E-Mountainbikes |
| Gender | Unisex |
Smart navigation. Brilliant OLED. Fully connected.
The Avinox DP100 combines a brilliant OLED display with intelligent navigation, extensive ride data and advanced connectivity. Its compact 2-inch screen keeps everything important clearly in view while maintaining a clean and integrated cockpit.
